UNS N08020 Floating Ball Valve, API 6D, 1 IN, CL 150 LB, SW

Key Specifications / Features

Model no.: JSC-240524-FBV-02

hits: 8
Introducing our UNS N08020 Floating Ball Valve: Crafted from forged Nickel Alloy 20 for durability and corrosion resistance. Compliant with API 6D standards, it ensures quality and reliability. Sized at 1 inch (DN25) for Class 150 LB and PN20 applications, it's ideal for diverse industries. With anti-static and fire-safe design features, it enhances safety in critical environments. Equipped with SW ends for secure sealing, our valve offers dependable performance in fluid control applications.
Request a quote

Detail Information


Forged Nickel Alloy Floating Ball Valve

Valve description: Ball valve, floating type, soft seat, bolted bonnet, two pieces 2PC, forged nickel alloy, full bore, anti-static fire-safe design, anti-stem blowout, locking device, Anti-corrosion.

Body material: UNS N08020
Design & Manufacture: API 6D
Ball material: UNS N08020
Nominal diameter: 1 Inch (DN25)
Nominal class: Class 150 LB (PN20)
Seat: RPTFE
Face to face: ASME B16.10
Test and inspection: API 598
End connection: SW
Mode of operation: Lever

The Forged Floating Ball Valve offers flexibility with both 2-piece and 3-piece body options, all crafted from durable forged steel. It boasts a range of connection types, including FF, RF, and RTJ Flange, as well as NPT, BW, and SW ends. Whether you need a Reduced Bore or Full Port configuration, customization is available upon request to suit specific needs.

We manufacture the following ball valves:

  1. Side Entry Design Forged Ball Valves
  2. End Entry Floating Ball Valve
  3. Long Pattern Forged Ball Valve
  4. Short Pattern Forged Ball Valve

SIZE RANGE AND PRESSURE CLASS

Size Range: 1/2 Inch to 8 Inch (DN15-DN200)
Pressure Range: Class 150 LB to 600 LB (PN16-PN100)

DESIGN STANDARDS

Design / Manufacture: MFG, API 6D, API 608, ISO 17292, EN-12516, ASME B16.34, DIN 3357, EN 13709, GB/T 12237, BS 5351
Face to Face Length (Dimension): MFG, API 6D, ASME B16.10, EN 558-1, GB/T 12221, DIN 3202
Flanged Dimension: ASME B16.5, EN 1092-1, BS 4504, DIN 2501
Testing: API 598, API 6D, EN 12266-1, EN 1074-1, ISO 5208, BS 6755-1

TECHNICAL FEATURES

  • Fully Compliant to ASME B16.34
  • Fully Compliant to API 608, API 6D, BS 5351
  • API 607 6th Edition Fire-Safe
  • All Models are NACE MR0175 Compliant
  • Submerged Packing System & Direct Mount Actuation
  • Standard ISO Actuator Mounting Pads on All Sizes
  • Standard Locking Stainless Steel Handles, Locking Bracket
  • Second Generation PTFE Seats Provide Higher Operating Temperatures
  • Standard Electrically Grounded Ball & Stem
  • All Sizes use Body Studs & Nuts for Ease of Disassembly
  • Forged material for dependable quality and performance
  • ASTM A961 Corrosion Protective Coating
  • Swing Out Construction for ease of installation
  • ISO Integral Mounting Pad
  • Anti-Static Device
  • Blowout Proof Stem
