Hastelloy C276 Floating Ball Valve, 1 IN, CL600, 2 Piece, BB

Key Specifications / Features

Model no.: JSC-20241009-FBV-04
Hits: 9
This Hastelloy C276 Floating Ball Valve is designed for 1-inch size (DN25) applications with a pressure rating of Class 600 LB (PN100). It features a 2-piece construction with a soft seat, bolted bonnet, and anti-static design for enhanced safety. The valve is fire-safe and comes with RF flanged connections, making it suitable for demanding industrial environments.
Request a quote

Detail Information


Hastelloy C276 Floating Ball Valve

Valve description: Ball valve, floating type, soft seat, bolted bonnet, two pieces, Hastelloy C276, full bore, anti-static, fire-safe

Body material: Hastelloy C276
Nominal diameter: DN25, 1 Inch
Nominal class: PN100, Class 600 LB
Soft seat: RPTFE
Mode of operation: lever
Face to face: ASME B16.10
Test and inspection: API 598
End connection: RF Flanged

Hastelloy valves provide superior service life and performance compared to standard SS 304/SS 316 valves, thanks to their exceptional corrosion resistance. They are widely utilized in the chemical, desalination, petrochemical, biotech, and pharmaceutical industries.

Various types of Hastelloy valves include Hastelloy B2, B3, C22, and C276, with corresponding UNS alloy designations such as N10665, N10276, N06022, N10675, and N06455. DIN specifications include 2.4617, 2.4600, 2.4602, and 2.4819. The most common cast Hastelloy forms used for valves are ASTM A494 CW12MW and ASTM A494 CX-2MW.

We manufacture the following ball valves:

Side Entry Design Forged Ball Valves
End Entry Floating Ball Valve
Long Pattern Forged Ball Valve
Short Pattern Forged Ball Valve

SIZE RANGE AND PRESSURE CLASS

Size Range: 1/2 Inch to 8 Inch (DN15-DN200)
Pressure Range: Class 150 LB to 600 LB (PN16-PN100)

DESIGN STANDARDS

Design / Manufacture: MFG, API 608, ISO 17292, EN 12516, ASME B16.34, DIN 3357, EN 13709, GB/T 12237, BS 5351
Face to Face Length (Dimension): MFG, API 6D, ASME B16.10, EN 558-1, GB/T 12221, DIN 3202
Flanged Dimension: ASME B16.5, EN 1092-1, BS 4504, DIN 2501
Testing: API 598, API 6D, EN 12266-1, EN 1074-1, ISO 5208, BS 6755-1

TECHNICAL FEATURES

1. Compliance Standards

Fully compliant with ASME B16.34
Compliant with API 608, API 6D, and BS5351
API 607 6th Edition Fire-Safe certified
All models meet NACE MR0175 requirements

2. Design and Construction

Submerged packing system with direct mount actuation
Standard ISO actuator mounting pads on all sizes
Swing-out construction for ease of installation
Anti-static device and blowout-proof stem

3. Materials and Durability

Forged materials for dependable quality and performance
ASTM A961 corrosion protective coating
Second-generation PTFE seats for higher operating temperatures

4. Additional Features

Standard locking stainless steel handles with a locking bracket
Electrically grounded ball and stem
Body studs and nuts for ease of disassembly
