Emergency Shutdown Ball Valve, API 6D, 2-48 IN, 150-2500 LB

Key Specifications / Features

Model No.: JSC-231117-TMBV-12

Hits: 12
Ensure swift and secure emergency shutdowns with our expertly crafted Emergency Shutdown Ball Valve. Available in both Forged and Casted Steel options, these valves feature a 2 or 3 Piece Split Body with a Side Entry design. Compliant with API 6D, ASME B16.34, and BS 5351 standards, these valves come in sizes ranging from 2 to 48 inches, with Class ratings of 150-2500 LB.
Request a quote

Detail Information

Emergency Shutdown Valve

Emergency Shutdown Valve (ESDV) controls process media flow and is responsible for isolating the supply of hazardous gasses and fluids within the pipeline in the event of an emergency. As a result, these valves provide more reliable performance than standard on-off valves.


SIZE RANGE AND PRESSURE CLASS

Size from 2 Inch to 48 Inch (DN50-DN1200)
Pressure from 150 LBS to 2500 LBS (PN16-PN420)


DESIGN STANDARDS

Design / Manufacture as per the standards: API 6D, ASME B16.34, DIN 3357, EN 13709, GB/T 12237, BS 5351, JIS B2071
Face to Face Length (Dimension) as per the standards: ASME B16.10 , EN 558-1 Gr. 14 (DIN 3202-F4) , DIN 3202-F5 , DIN 3202-F7 , BS 5163
Flanged Dimension according to the standards: ASME B16.5 , EN 1092-1, BS 4504, DIN 2501, Flanged to ASME B16.5 (2 - 24 Inch) and ASME B16.47 Series A / B (26 Inch and above) Clamp / Hub ends on request.
Testing according to the standards: API 598, API 6D, EN 12266-1, EN 1074-1, ISO 5208, DIN2401, JIS B2003


TECHNICAL FEATURES

Cast Steel, or Forged Steel
2 piece or 3 piece, Split body, Side Entry,
Tight Shut Off
Fire Safe
Fast-Acting
Manual and Automatic Release Options
Rugged Design
Customizable Configurations
Certified Safety Integrity Level (SIL) per IEC 61508
Capable of Both Local and Remote Partial Stroke Test
Full Open Position – Normal Operation
Full Closed Position – Emergency Situation
No operation disruptions
Eliminates need for bypass line
Improved SIL rating
Prevention and diagnoses potential problems
Even while testing, the valve will still shut if emergency signal received


CONSTRUCTION MATERIALS

General Cast Carbon Steel
ASTM A216 WCB, WCC, WCA, GP240GH 1.0619 / GS-C25
ASTM A105, C22.8/ P250GH (1.0460/1.0432)

Low Temperature Carbon Steel (LTCS):
ASTM A352 LCB, LCC, LCA, GS-CK25
ASTM A350 LF2, TStE 355 / P355QH1 (EN 1.0571/1.0566)

Alloy Steel:
ASTM A352 LC1, LC2, LC2-1, LC3, LC4, LC9, ASTM A743 CA6NM
GS-CK16, GS-CK24, GS-10Ni6, GS-10ni14
ASTM A350 LF1, LF3, LF5, LF6, LF9, LF787

High Temperature Steel (Chrome Moly)/Alloy Steel:
ASTM A217 WC1, WC6, WC9, C5, C12, C12A,
GS-22Mo4 / G20Mo5 (EN 1.5419), GS-17CrMo55 / G17CrMo5-5 (EN 1.7357)
ASTM A182 F1, 15Mo3 16Mo3 (EN 1.5415)
ASTM A182 F11, 13 CrMo 4 4 / 13CrMo4-5 (EN 1.7335)
ASTM A182 F22, 10CrMo 9 10 / 11CrMo9-10 (EN 1.7383/1.7380)
ASTM A182 F91, X10CrMoVNb9-1 (EN 1.4903)

Austenitic Stainless Steel/Alloy Steel:
UNS S30400, S30403, S30409, ASTM A351 CF8, CF3, CF10
G-X6CrNi189 / GX5CrNi19-10 (EN 1.4308)
UNS S31600, S31603, S31609, ASTM A351 CF8M, CF3M. CF10M
GX5CrNiMo19-11-2 / G-X6CrNiMo18.10 (EN 1.4408)
UNS S34700, S34709, ASTM A351 CF8C
G-X5CrNiNb189 / GX5CrNiNb19-11 (EN 1.4552)
AISI 316Ti, X6CrNiNo17122 / X6CrNiMoTi17-12-2 (EN 1.4571)
ALLOY 20 / UNS N08020, ASTM A351 CN7M
ASTM A182 F304 X5CrNi1810 / X5CrNi18-10 (EN 1.4301)
ASTM A182 F304L X2 CrNi 19 11 (EN 1.4306)
ASTM A182 F316 X5CrNiMo 17 12 2 / X5CrNiMo17-12-2 (EN 1.4401)
ASTM A182 F316L X2 CrNiMo 17 13 2 / X2CrNiMo17-12-2 (EN 1.4404)
ASTM A182 F316 Ti X6 CrNiMoTi 17 12 2 / X6CrNiMoTi17-12-2 (EN 1.4571)
ASTM A182 F321 X6 CrNiTi 18 10 / X6CrNiTi18-10 (EN 1.4541)
ASTM A182 F347 X6CrNiNb1810 / X6CrNiTi18-10C (EN 1.4550)
ASTM A182 F44 (6MO) (EN 1.4547)
ASTM A182 F20 * (ALLOY 20)

Ferritic-Austenitic / Duplex / Super Duplex Stainless Steel:
UNS S31803 / S32205 (Duplex 2205), ASTM A890/A995 GR.4A (UNS J92205) / A351 CD3MN
UNS S32750 (Super Duplex 2507), ASTM A890 / A995 GR.5A / A351 CE8MN (CD4MCu)
UNS S32760, ASTM A890 / A995 GR.6A (CD3MWCuN)
ASTM A182 F51, X2 CrNiMoN 22 5 3 / X2CrNiMoN22-5-3 (EN 1.4462)
ASTM A182 F52 (EN 1.4460)
ASTM A182 F53, X2CrNiMoCuN 25.6.3 (EN 1.4410)
ASTM A182 F55, X2CrNiMoCuWN 25.7.4 (EN 1.4501)
ASTM A182 F60 (EN 1.4462)

Other Materials:
Alloy 20 ASTM B462 / UNS N08020
Monel 400 / UNS N04400 ASTM B564-N04400 / A494 M35-1 NiCu30Fe (EN 2.4360)
Nickel Alloy 904L / UNS N08904 X1NiCrMoCu25.20.5 (EN 1.4539)
Inconel 625 / UNS N06625 / ASTM B564-N06625 / ASTM A494-CW6MC
NiCr22Mo9Nb (EN 2.4856)
Inconel 825 / UNS N08825 / ASTM B564-N08825 / ASTM A494 CU5MCuC (EN 2.4858)
NiCr21Mo (EN 2.4858)
