Socket Weld Ball Valve, API 6D, 608, 1/2-4 Inch, 150-2500 LB
Key Specifications / Features
Model No.: JSC-231117-FBV-22 Hits: 5
Discover precision and reliability with our Socket Weld Ball Valve, expertly fabricated to meet API 6D, API 608, ASME B16.34, and JIS B2071 standards. Available in sizes ranging from 1/2 to 4 inches, with Class ratings spanning 150-2500 LB, these valves feature options for Full or Reduced Port configurations, ensuring versatility in various applications. With a Fire-Safety Design and SW Ends, our valves provide optimal performance and safety in critical industrial processes.
Request a quote
Tags:
Detail Information
Socket Weld Ball Valve
We offers the best possible design for socket weld end ball valve. The socket-welded ball valve is a valve that uses a sphere with a circular channel as the opening and closing part. The sphere rotates with the valve stem to realize the opening and closing action. The socket-welding ball valve has a holed sphere around the opening and closing part perpendicular to the channel. The axis rotates to achieve the purpose of opening and closing the channel. Available with integral nipples.
We also provide the following ball valves
Socket weld end ball valve
Seal welded ball valve
Seal Welded High Pressure Ball Valve, Socket Weld Ends
Maintenance Design Ball Valve, Socket Weld Ends
Extended Butt Weld Ends Ball Valve
SIZE RANGE AND PRESSURE CLASS
Size from 1/2 Inch to 4 Inch (DN15-DN100)
Pressure from 150 LBS to 2500 LBS (PN16-PN420)
DESIGN STANDARDS
Design / Manufacture as per the standards: MFG, API 6D, API 608, ASME B16.34, DIN 3357, EN 13709, GB/T 12237, BS 5351, JIS B2071
Face to Face Length (Dimension) as per the standards: MFG, ASME B16.10, EN 558-1 Gr. 14 (DIN 3202-F4), DIN 3202-F5, DIN 3202-F7, BS 5163
Socket Weld Ends Standard: ASME B16.11, EN 12627, BS 2080, GB/T 12224, DIN 3239
Testing according to the standards: API 598, API 6D, EN 12266-1, EN 1074-1, ISO 5208, DIN2401, JIS B2003
TECHNICAL FEATURES
Fire-Safety Design
Full and Reduced Port Sizes are available
All Models are NACE MR0175 Compliant
Elongated Packing Gland for Ease of Access When Automated
Standard ISO Actuator Mounting Pads on All Sizes
Standard Locking Stainless Steel Handles
Electrically Grounded Stem
Optional PEEK Seats/Metal Seats for High Temp Services
Regular port, Split body design, Socket welding ends
Three-piece body design, Threaded or socket welding ends
Regular port, Three-piece body design, Threaded or socket welding ends
Blowout-proof stem
Swing-away body for maintenance ease
Socket welding ends to BS 5351
Socket welding ends to ASME B16.11
CONSTRUCTION MATERIALS
General Cast Carbon Steel:
ASTM A216 WCB, WCC, WCA, GP240GH 1.0619 / GS-C25
ASTM A105, C22.8/ P250GH (1.0460/1.0432)
Low Temperature Carbon Steel (LTCS):
ASTM A352 LCB, LCC, LCA, GS-CK25
ASTM A350 LF2, TStE 355 / P355QH1 (EN 1.0571/1.0566)
Alloy Steel:
ASTM A352 LC1, LC2, LC2-1, LC3, LC4, LC9, ASTM A743 CA6NM
GS-CK16, GS-CK24, GS-10Ni6, GS-10ni14
ASTM A350 LF1, LF3, LF5, LF6, LF9, LF787
High Temperature Steel (Chrome Moly) / Alloy Steel:
ASTM A217 WC1, WC6, WC9, C5, C12, C12A
GS-22Mo4 / G20Mo5 (EN 1.5419), GS-17CrMo55 / G17CrMo5-5 (EN 1.7357)
ASTM A182 F1, 15Mo3 16Mo3 (EN 1.5415)
ASTM A182 F11, 13 CrMo 4 4 / 13CrMo4-5 (EN 1.7335)
ASTM A182 F22, 10CrMo 9 10 / 11CrMo9-10 (EN 1.7383/1.7380)
ASTM A182 F91, X10CrMoVNb9-1 (EN 1.4903)
Austenitic Stainless Steel / Alloy Steel:
UNS S30400, S30403, S30409, ASTM A351 CF8, CF3, CF10
G-X6CrNi189 / GX5CrNi19-10 (EN 1.4308)
UNS S31600, S31603, S31609, ASTM A351 CF8M, CF3M. CF10M
GX5CrNiMo19-11-2 / G-X6CrNiMo18.10 (EN 1.4408)
UNS S34700, S34709, ASTM A351 CF8C
G-X5CrNiNb189 / GX5CrNiNb19-11 (EN 1.4552)
AISI 316Ti, X6CrNiNo17122 / X6CrNiMoTi17-12-2 (EN 1.4571)
ALLOY 20 / UNS N08020, ASTM A351 CN7M
ASTM A182 F304 X5CrNi1810 / X5CrNi18-10 (EN 1.4301)
ASTM A182 F304L X2 CrNi 19 11 (EN 1.4306)
ASTM A182 F316 X5CrNiMo 17 12 2 / X5CrNiMo17-12-2 (EN 1.4401)
ASTM A182 F316L X2 CrNiMo 17 13 2 / X2CrNiMo17-12-2 (EN 1.4404）
ASTM A182 F316 Ti X6 CrNiMoTi 17 12 2 / X6CrNiMoTi17-12-2 (EN 1.4571)
ASTM A182 F321 X6 CrNiTi 18 10 / X6CrNiTi18-10 (EN 1.4541)
ASTM A182 F347 X6CrNiNb1810 / X6CrNiTi18-10C (EN 1.4550)
ASTM A182 F44 (6MO) (EN 1.4547)
ASTM A182 F20 * (ALLOY 20)
Ferritic-Austenitic / Duplex / Super Duplex Stainless Steel:
UNS S31803 / S32205 (Duplex 2205), ASTM A890/A995 GR.4A (UNS J92205) / A351 CD3MN
UNS S32750 (Super Duplex 2507), ASTM A890 / A995 GR.5A / A351 CE8MN (CD4MCu)
UNS S32760, ASTM A890 / A995 GR.6A (CD3MWCuN)
ASTM A182 F51, X2 CrNiMoN 22 5 3 / X2CrNiMoN22-5-3 (EN 1.4462)
ASTM A182 F52 (EN 1.4460)
ASTM A182 F53, X2CrNiMoCuN 25.6.3 (EN 1.4410)
ASTM A182 F55, X2CrNiMoCuWN 25.7.4 (EN 1.4501)
ASTM A182 F60 (EN 1.4462)
Other Materials:
Alloy 20 ASTM B462 / UNS N08020
Monel 400 / UNS N04400 ASTM B564-N04400 / A494 M35-1 NiCu30Fe (EN 2.4360)
Nickel Alloy 904L / UNS N08904 X1NiCrMoCu25.20.5 (EN 1.4539)
Inconel 625 / UNS N06625 / ASTM B564-N06625 / ASTM A494-CW6MC
NiCr22Mo9Nb (EN 2.4856)
Inconel 825 / UNS N08825 / ASTM B564-N08825 / ASTM A494 CU5MCuC (EN 2.4858)
NiCr21Mo (EN 2.4858)
