Cast Steel Floating Ball Valve, 2 Piece, 1/2-12 IN, 150-600 LB
Key Specifications / Features
Model No.: JSC-231117-FBV-26 Hits: 9
As a leading producer of Cast Steel Floating Ball Valves, we offer precision-engineered solutions for diverse industrial applications. Available in sizes ranging from 1/2 to 12 inches, with Class ratings from 150 to 600 LB, our valves feature a versatile 2-Piece, Split Body design. Choose between Full Port and Regular Port options, ensuring optimal performance in accordance with API 608, BS 5351, ISO 17292, and DIN 3357 standards.
Request a quote
Tags:
Detail Information
Cast Steel Floating Ball Valve
Cast steel floating ball valves are featured with two-piece bolted carbon steel with flanged end body and floating ball. The ball valve is available in size from 1/2 Inch to 12 Inch full port or regular port and offers ANSI class rating 150 to 600, All valves meet the requirements of BS 5351, 6755 and API 607.
We also manufactures the following ball valves,
Split-Body Full Port Flanged Ball Valve
Two-piece, split body, cast steel, side entry design
Long Pattern Floating Ball Valve,
Short Pattern Floating Ball Valve,
SIZE RANGE AND PRESSURE CLASS
Size from 1/2 Inch to 12 Inch (DN15-DN300)
Pressure from 150 LBS to 600 LBS (PN16-PN100)
DESIGN STANDARDS
Design / Manufacture as per the standards: API 608, ISO 17292, EN-12516, ASME B16.34, DIN 3357, EN 13709, GB/T 12237, BS 5351,JIS B2071, MFG
Face to Face Length (Dimension) as per the standards: MFG, API6D, ASME B16.10, EN 558-1, BS 5163, GB/T 12221, DIN 3202
Flanged Dimension according to the standards: ASME B16.5, EN 1092-1, BS 4504, DIN2501,
Testing according to the standards: API 598, API 6D, EN 12266-1, EN 1074-1, ISO 5208, BS 6755-1
TECHNICAL FEATURES
Two Piece, Split Body
Encapsulated seat
Mounting pad
Full Bore Floating Ball Valve,
Reduce bore Floating Ball Valve,
Full bore floating ball valve, ASME integral flanged
Cryogenic floating ball valve
Full Port, Split Body, Side Entry Design Ball Valves
Regular Port, Uni-body, End Entry Design Ball Valves
Regular Port, Uni-body, End Entry Design Ball Valves
Double "D" Stem Head Provides mounting of the lever handle always in parallel to the flow passage.
ISO 5211 mounting yoke easily for installation of gear, motor or pneumatic actuator
Blow-out Proof Stem Internally inserted and functions as the backseat for assured stem sealing at all pressures
Metal-to-Metal Sealing When non-meatl sealing is deteriorated by fire, ball floats to shut off the line fruid
Emission-free Graphite primary gasket
CONSTRUCTION MATERIALS
General Cast Carbon Steel:
ASTM A216 WCB, WCC, WCA, GP240GH 1.0619 / GS-C25
ASTM A105, C22.8/ P250GH (1.0460/1.0432)
Low Temperature Carbon Steel (LTCS):
ASTM A352 LCB, LCC, LCA, GS-CK25
ASTM A350 LF2, TStE 355 / P355QH1 (EN 1.0571/1.0566)
Alloy Steel:
ASTM A352 LC1, LC2, LC2-1, LC3, LC4, LC9, ASTM A743 CA6NM
GS-CK16, GS-CK24, GS-10Ni6, GS-10ni14
ASTM A350 LF1, LF3, LF5, LF6, LF9, LF787
High Temperature Steel (Chrome Moly) / Alloy Steel:
ASTM A217 WC1, WC6, WC9, C5, C12, C12A
GS-22Mo4 / G20Mo5 (EN 1.5419), GS-17CrMo55 / G17CrMo5-5 (EN 1.7357)
ASTM A182 F1, 15Mo3 16Mo3 (EN 1.5415)
ASTM A182 F11, 13 CrMo 4 4 / 13CrMo4-5 (EN 1.7335)
ASTM A182 F22, 10CrMo 9 10 / 11CrMo9-10 (EN 1.7383/1.7380)
ASTM A182 F91, X10CrMoVNb9-1 (EN 1.4903)
Austenitic Stainless Steel / Alloy Steel:
UNS S30400, S30403, S30409, ASTM A351 CF8, CF3, CF10
G-X6CrNi189 / GX5CrNi19-10 (EN 1.4308)
UNS S31600, S31603, S31609, ASTM A351 CF8M, CF3M. CF10M
GX5CrNiMo19-11-2 / G-X6CrNiMo18.10 (EN 1.4408)
UNS S34700, S34709, ASTM A351 CF8C
G-X5CrNiNb189 / GX5CrNiNb19-11 (EN 1.4552)
AISI 316Ti, X6CrNiNo17122 / X6CrNiMoTi17-12-2 (EN 1.4571)
ALLOY 20 / UNS N08020, ASTM A351 CN7M
ASTM A182 F304 X5CrNi1810 / X5CrNi18-10 (EN 1.4301)
ASTM A182 F304L X2 CrNi 19 11 (EN 1.4306)
ASTM A182 F316 X5CrNiMo 17 12 2 / X5CrNiMo17-12-2 (EN 1.4401)
ASTM A182 F316L X2 CrNiMo 17 13 2 / X2CrNiMo17-12-2 (EN 1.4404）
ASTM A182 F316 Ti X6 CrNiMoTi 17 12 2 / X6CrNiMoTi17-12-2 (EN 1.4571)
ASTM A182 F321 X6 CrNiTi 18 10 / X6CrNiTi18-10 (EN 1.4541)
ASTM A182 F347 X6CrNiNb1810 / X6CrNiTi18-10C (EN 1.4550)
ASTM A182 F44 (6MO) (EN 1.4547)
ASTM A182 F20 * (ALLOY 20)
Ferritic-Austenitic / Duplex / Super Duplex Stainless Steel:
UNS S31803 / S32205 (Duplex 2205), ASTM A890/A995 GR.4A (UNS J92205) / A351 CD3MN
UNS S32750 (Super Duplex 2507), ASTM A890 / A995 GR.5A / A351 CE8MN (CD4MCu)
UNS S32760, ASTM A890 / A995 GR.6A (CD3MWCuN)
ASTM A182 F51, X2 CrNiMoN 22 5 3 / X2CrNiMoN22-5-3 (EN 1.4462)
ASTM A182 F52 (EN 1.4460)
ASTM A182 F53, X2CrNiMoCuN 25.6.3 (EN 1.4410)
ASTM A182 F55, X2CrNiMoCuWN 25.7.4 (EN 1.4501)
ASTM A182 F60 (EN 1.4462)
Other Materials:
Alloy 20 ASTM B462 / UNS N08020
Monel 400 / UNS N04400 ASTM B564-N04400 / A494 M35-1 NiCu30Fe (EN 2.4360)
Nickel Alloy 904L / UNS N08904 X1NiCrMoCu25.20.5 (EN 1.4539)
Inconel 625 / UNS N06625 / ASTM B564-N06625 / ASTM A494-CW6MC
NiCr22Mo9Nb (EN 2.4856)
Inconel 825 / UNS N08825 / ASTM B564-N08825 / ASTM A494 CU5MCuC (EN 2.4858)
NiCr21Mo (EN 2.4858)
