Cast Steel Y Strainer, ASME B16.34, 1/2-24 Inch, 150-600 LB
Key Specifications / Features
Model No.: JSC-231124-YS-116 Hits: 4
Enhance your liquid filtration system with our ASME B16.34 Cast Steel Y Strainers. Available in sizes ranging from 1/2 to 24 inches and suitable for 150-600 LB applications, these strainers are ideal for diverse setups. Crafted from casted carbon, stainless, and alloy steel, they boast durability. The incorporation of SS 304 and SS 316 screens ensures effective filtration.
Request a quote
Tags:
Detail Information
Cast Steel Y Strainer
Y-type filter is used in water, oil and gas pipelines and various equipment. It mainly removes the medium in the pipe to protect the pressure reducing valve, pressure relief valve, constant water level valve and water pump, so as to achieve normal operation. Please install it at the inlet. Generally, the water filter screen is 10-30 mesh / cm2, the air filter screen is 40-100 mesh / cm2, and the oil filter screen is 60-200 mesh / cm2.
The Y-type strainer is installed at the front end of each matching valve in the water inlet pipeline. When the medium in the pipeline enters the filter first, the medium enters into the connected valve through the filter screen, and the impurities are left in the filter barrel, so that all kinds of valves will not be lost due to mechanical debris stuck in the sealing ring.
Cast Steel Y Strainer-Features
The Y-type strainer screen adopts stainless steel double-layer net structure, which is firm and durable, and has the characteristics of advanced structure, small flow resistance and convenient sewage discharge.
The mesh number of the filter screen should be set according to the user's needs. Generally, the mesh size of water supply network is 18-30 mesh, that of ventilation network is 40-100 mesh, and that of oil mesh is 100-480 mesh.
A blow down plug on the drain port will allow clean-out without removal of the screen and without interrupting the process flow, provided on request.
SS 304 perforated screens are standard.
Drain/Blow-off connection furnished with plug as standard.
Cast Steel Y Strainer-Specifications and materials
Design: ASME B16.34
Face to Face: ASME B16.10
Flange Ends: ASME B16.5
Butt-weld Ends: ASME B16.25
Threaded Ends: ASME B1.20.1
Socket-weld Ends: ASME B16.11
Valves Marking Conform: MSS SP-25
Inspection and Testing Conform: API 598
Body material: ASTM A216 WCB, ASTM A352 LCB, Alloy Steel ASTM A217 WC6, WC9, Stainless Steel ASTM A351 CF8 CF8M, CF3, CF3M, Duplex A890 4A, 5A, Special Alloy, Monel, Bronze C95800, Alloy 20.
Size Range: 1/2 - 24 Inch, DN15 - DN600
Pressure Range: Class 150 LB - 600 LB, PN20 - PN100
