Carbon Steel Swing Check Valve, BS 1868, WCB, 5 Inch, 300 LB

BS 1868 Swing Check Valve

Valve description: Swing check valve, bolted bonnet, renewable seat, stellite face

Body material: ASTM A216 WCB
Nominal diameter: 5 Inch (DN125)
Nominal class: Class 300 LB (PN50)
Metal seat: STL
End connection: RTJ
Design and Manufacture: BS 1868
Face to face: ASME B16.10
Test and inspection: API 598

BS 1868 swing check valve prevents potentially damaging backflows to protect equipment like as pumps and compressors. The Non-return valves allow the flow of the fluid in one direction only and block reverse flows. It has the simplest design and operates via a metallic disc attached to a hinge at the top. When the fluid passes through the swing check valve, then the valve is open. When a reverse flow occurs, the changes in motion as well as gravity help to close the disc, closing the valve and preventing backflows.

BS 1868 Swing Check Valve - Standard

Welding seat rings or Renewable seat rings
Design and Manufacture: BS 1868 or ASME B16.34
Inspection and Test: API 598
End flange dimension: ASME B16.5, ASME B16.47 (API 605, MSS SP-44)
BW end dimension: ASME B16.25
Face to face, end to end: ASME B16.10
Pressure-temperature ratings: ASME B16.34
NACE: NACE 0175
Size Range: 2 Inch – 36 Inch (DN50-DN900)
Pressure Range: ASME Class 150- 2500LB (PN20-PN420)
Materials: ASTM A216 WCB, WCC, ASTM A217 WC1, WC6, WC9, ASTM A351 CF8, A351 CF8M, A351 CF3, A351 CF3M, A351 CN7M, ASTM A352 LC1, LCB, LCC, LC3, Hastelloy C276, Monel, Titanium and Alloy 20 (Cast Steel, Alloy Steel, Stainless Steel, Special Steel)
