ASTM A216 WCB Swing Check Valve, BS 1868, 24 Inch, CL 150 LB

Key Specifications / Features

Model No.: JSC-240511-SCV-01

Hits: 2
Our plant in China specializes in manufacturing carbon steel swing check valves designed to BS 1868 standards. These valves are crafted from ASTM A216 WCB and are available in a size of 24 inches (DN600), suitable for Class 150 LB or PN20 applications. Featuring a bolted bonnet and STL metal seat, they ensure reliable performance and are equipped with flanged ends for easy installation.
Request a quote

Detail Information


BS 1868 Swing Check Valve

Valve description: Swing check valve, bolted bonnet, renewable seat, stellite face, Carbon steel

Design and Manufacture: BS 1868
Body material: ASTM A216 WCB
Nominal diameter: 24 Inch (DN600)
Nominal class: Class 150 LB (PN20)
Metal seat: STL
Face to face: ASME B16.10
Test and inspection: API 598
End connection: flange
Mode of operation: /

BS 1868 Swing Check Valve Features

Standard trim is stellite faced seat and disc seat surfaces
Easy in-line service
All parts are easily accessible for maintenance
Seating faces can be re-lapped
Full Open and regular port as optional
Suitable for Vertical or Horizontal installation
Welding seat rings or Renewable seat rings

BS 1868 Swing Check Valve Product Range

Welding seat rings or Renewable seat rings
Design and Manufacture: BS 1868 or ASME B16.34
Inspection and Test: API 598
End flange dimension: ASME B16.5, ASME B16.47 (API 605, MSS SP-44)
BW end dimension: ASME B16.25
Face to face, end to end: ASME B16.10
Pressure-temperature ratings: ASME B16.34
NACE: NACE 0175
Size Range: 2 Inch – 36 Inch (DN50-DN900)
Pressure Range: ASME Class 600 – 2500 LB (PN100-PN420)
Materials: ASTM A216 WCB, WCC, ASTM A217 WC1, WC6, WC9, ASTM A351 CF8, A351 CF8M, A351 CF3, A351 CF3M, A351 CN7M, ASTM A352 LC1, LCB, LCC, LC3, Hastelloy C276, Monel, Titanium and Alloy 20 (Cast Steel, Alloy Steel, Stainless Steel, Special Steel)
