ASTM A105N Swing Check Valve, 1-1/2 Inch, 300 LB, Metal Seat

Key Specifications / Features

Model No.: JSC-240428-SCV-02

Hits: 29
Explore our forged swing check valve, meticulously crafted from ASTM A105N material in accordance with API 602 standards, ensuring robustness and reliability. With a size of 1-1/2 inches and a pressure rating of Class 300 LB, it offers versatility and resilience for various industrial applications. The valve is equipped with a durable 13Cr metal seat, ensuring secure sealing and long-term performance.
Request a quote

Detail Information


Forged Swing Check Valve

Body material: ASTM A105N
Nominal diameter: 1-1/2 Inch (DN40)
Nominal class: Class 300 LB (PN50)
End connection: RF
Metal seat: 13Cr
Design: API 602
Face to face: MFR, API 602
Mode of operation: /
Test and inspection: API 598

Forged steel check valves rely on the flow of the medium itself to automatically open and close the valve disc. They are used to prevent the reverse flow of the medium and are also known as check valves, one-way valves, reverse flow valves, and back pressure valves. The body guide ensures alignment of the seat and disc. When the piston check valve closes, the flow pressure will force the disc to lift off the seat, allowing fluid to pass through the valve.

Forged Steel Swing Check Valve -Features

1. The body is forged steel and available in reduced and full bore design
2. Bolted bonnet, Welded Bonnet or Pressure Seal Bonnet
3. Spring loaded piston
4. Integral seat

Forged steel swing check valve- Specifications and Standards

1. Design standard: API 602, ASME 16.34
2. Pressure temperature standard: ASME 16.34
3. Face to face dimension: MFR Standard
4. Testing and inspection standard: API 598
5. Flanged Ends: ASME B16.5
6. Butt Welded Ends: ASME B16.25
7. Screwed Ends: ASME B1.20.1
8. Socket Welded Ends: ASME B16.11
9. Ends: Flanged ends, Socket Weld End, Screwed End, Butt-weld end
10. Size range: 1/2 Inch - 3 Inch (DN15-DN80)
11. Pressure Range: Class 150 LB, 300 LB, 600 LB, 900 LB, 1500 LB, 2500 LB, 4500 LB
12. Body material: ASTM A105N, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, ASTM A182 F55, Inconel Alloy, Monel Alloy, Hastelloy Alloy.
13. Trim material: ASTM A182 F6a, F316, F304, F316L, F321, F51, F55, Inconel, Stellied or Hardfaced
