Maintenance and Cleaning Procedures of Cryogenic Ball Valves


Cryogenic ball valves are vital for fluid control at very low temperatures. Their stability and function are critical. Proper maintenance and regular cleaning ensure these ball valves function optimally. This will make sure they are reliable and safe. This article will provide a complete guide to cryogenic ball valve maintenance. It covers preparation, cleaning, and assembly. It will help you operate the ball valves and keep them in optimal condition.

Pressure Management in Closed State


When a cryogenic ball valve is closed, there may still be pressurized fluid inside the valve. This requires careful pressure management.

Check Valve Body Pressure: Even if the valve is closed, there may be pressure inside. Before starting, you must check the valve's actual pressure. You also need to monitor it. This stops accidents from pressure changes during use.

To do maintenance or cleaning, you must open the valve. First, let out the pressure inside it. A sudden release could cause liquid or gas to spray out, posing a danger. Pressure should be released slowly and safely. This protects people and equipment from harm.

Test the pressure before maintenance. This test ensures that the pipeline and valve system pressures are safe. This helps identify any potential pressure issues.

Monitor Pressure Changes: Keep an eye on pressure changes during valve operation. This is especially important when first opening the valve. Pay close attention to any abnormal pressure fluctuations and take immediate action.

Safety Measures: Always wear the right safety gear. This gear includes gloves and goggles. It prevents accidental injury during pressure release.

Preparation Before Maintenance


Before maintenance, ensure that the pipeline pressure is relieved. Also, ensure the valve is open. This is for safety during repairs.

Disconnect the Power or Air Supply. This will cut the power or air supply for the valve. It will prevent accidental activation during operation.

Remove the Actuator from the Mounting. Do this before going further to make disassembly easier.

Confirm Pipeline Pressure


Before disassembling the cryogenic ball valve, it is essential to ensure that the pressure within the pipeline has been completely relieved to guarantee safety during the disassembly process.

Check Upstream and Downstream Pressures: Before disassembling the valve, check the pressure conditions in the upstream and downstream pipelines. Ensure that all related pipeline pressures have been reduced to a safe range to avoid accidents during disassembly.

Use a Pressure Gauge: Use a pressure gauge or other measuring tools to accurately measure the pressure inside the pipeline. Record the pressure values and compare them with normal safe values to ensure that the pressure has been completely released.

Confirm No Pressure: Before disassembly, ensure that there is no residual pressure in the pipelines on both sides of the valve. This can be confirmed by releasing the pressure at both ends of the valve to ensure that the disassembly process is not affected by pressure.

Record and Mark: Record and mark all results of the pressure test, and log any abnormalities in the maintenance log. This helps track the pressure status in subsequent operations and ensures smooth maintenance work.

Safety Confirmation: After confirming that the pressure has been completely released, proceed with disassembly. This step effectively prevents safety issues caused by residual pressure in the pipeline.

Disassembly and Assembly Considerations


Handle Parts Carefully: During disassembly and reassembly, be careful to prevent damage to the sealing surfaces of parts, especially non-metal parts. When removing O-rings, it is recommended to use specialized tools to avoid damage.

Assembly of Flanged Connections: For cryogenic ball valves with flanged connections, the bolts on the flanges should be tightened symmetrically, gradually, and evenly during assembly to ensure the sealing and stability of the connection.

Assembly of Welded Connections: During the assembly of cryogenic ball valves with welded connections, appropriate cooling treatment of the valve body is required to avoid damage from excessive heat generated during welding.

Selection and Use of Cleaning Agents


Choose the Right Cleaning Agent: The cleaning agent should be compatible with the rubber, plastic, metal parts, and working medium in the ball valve. For gaseous working media, gasoline can be used to clean metal parts; non-metal parts should be cleaned with pure water or alcohol.

Cleaning Method:

Disassembled Parts: For individual parts that have been disassembled, soaking in a cleaning solution can be used for cleaning.

Non-disassembled Parts: Metal parts with non-metal parts that have not been disassembled can be cleaned with a clean, fine cloth soaked in cleaning agent, ensuring the removal of all grease, dirt, accumulated glue, and dust.

Drying and Assembly


Handling of Non-metal Parts: Non-metal parts of the cryogenic ball valve should be immediately removed from the cleaning agent after cleaning to prevent deterioration from prolonged soaking.

Post-cleaning Drying: After cleaning, wait for the cleaning agent on the washed surface to fully evaporate before assembly. If left for a long time, it may lead to rusting or contamination with dust.

Cleaning of New Parts: New parts should also be thoroughly cleaned before assembly and dried with a hairdryer to ensure that the surface is clean and free of foreign objects.

Preventing Contamination


During the assembly of cryogenic ball valves, strict measures must be taken to prevent contamination to ensure the normal operation and long life of the valve. Specific measures include:

Maintain a Clean Work Environment: Ensure that the work environment for maintenance and assembly is clean to reduce dust, impurities, and other sources of pollution.

Avoid Metal Debris: During disassembly and assembly, be cautious to prevent metal debris from entering the valve interior. Use appropriate tools and clean clothes to ensure that part surfaces are clean.

Inspect Parts: Before assembly, inspect all parts for grease, dust, welding slag, or other foreign objects. Ensure that part surfaces are free from contamination.

Prevent Foreign Objects: During cleaning and assembly, avoid any foreign objects from entering the valve interior. Thoroughly clean all disassembled parts to ensure no residue remains.

By following the above maintenance and cleaning guidelines, the performance and safety of the cryogenic ball valve can be effectively maintained. The maintenance not only extends the service life of the valve, but also ensures the reliability of the valve under extreme working conditions. Ensure that each step is carefully executed to ensure that all components are clean and pollution-free, and that meticulous operation is carried out during assembly to achieve the best operating results of the cryogenic ball valve.
