Essential Guide to Professional Industrial Valve Installation


Industrial valves are the linchpin in fluid control and the cornerstone of ensuring system safety, efficiency, and reliability. The proper installation of industrial valves is crucial for realizing their designed functions. However, due to the wide variety of valve types and the complex and ever-changing application environments, the installation process is often fraught with challenges. To assist engineers and technical personnel in overcoming these challenges, this article provides a comprehensive guide to the installation of industrial valves, aiming to ensure professionalism and efficiency in valve installation through in-depth analysis and practical tips.

Preparation Before Industrial Valve Installation


Adequate preparation before installing industrial valves is essential. This involves not only inspecting and cleaning the valves themselves but also assessing the installation environment and preparing the necessary tools. Here are some key preparatory steps that lay a solid foundation for subsequent installation work.

1. Valve Selection and Specification Verification


Select the appropriate model and specifications of the valve based on the process flow, medium characteristics, and operating conditions.
Ensure the compatibility of the valve material with the medium to avoid chemical reactions or corrosion issues.
Verify that the valve meets the design parameters, including pressure class, temperature range, and connection sizes.

2. Cleaning and Inspection


Thoroughly clean the internal and external surfaces of the valve to remove any residual cutting fluids, rust, or impurities from the manufacturing process.
Inspect the interior of the valve for any damage or deformation, ensuring that the sealing surfaces are smooth and undamaged.
Check the valve's operating mechanisms, such as hand wheels and gearboxes, to ensure they are flexible and free of obstruction.

3. Environmental Assessment


Assess the temperature, humidity, and corrosiveness of the valve installation environment, and choose suitable protective measures.
Consider the performance of the valve under extreme conditions, such as low-temperature embrittlement or high-temperature creep.

Industrial Valve Installation Process


The correct installation method not only extends the service life of the valve but also ensures its efficient operation within the system.

1. Initial Positioning


Ensure that the valve is fully closed before installation to prevent medium leakage.
For large valves, install them vertically or horizontally according to the manufacturer's recommendations to accommodate their self-weight and operating forces.

2. Bolt Connection and Tightening


Use bolts and nuts of the appropriate specifications to ensure that the connecting parts match the material of the valve.
Tighten the bolts in a cross-symmetric manner step by step to avoid local over-tightening that could cause valve deformation.
Use a torque wrench to finally tighten the bolts according to the manufacturer's recommended torque values.

3. Valve Operating Direction


Determine the correct installation direction based on the type of valve and the characteristics of the medium to optimize fluid dynamics performance.
For gate valves, ensure that the direction of the medium flow is consistent with the arrow marked on the valve body to avoid fluid impact.

4. Installation of Special Valves


For cryogenic valves, consider multiple open and close operations before cooling to adapt to temperature changes.
For high-temperature valves, consider the impact of thermal expansion on bolt tightening and adjust the tightening torque in a timely manner.

Post-Installation Inspection and Testing


After installation, a thorough inspection and testing of the valve are indispensable. This helps to ensure the performance and reliability of the valve under actual working conditions.

Seal Performance Test: After valve installation, conduct a pressure test to verify the seal performance and ensure no leaks. For critical valves, perform a leak rate test to meet strict sealing requirements.

Operating Performance Check: Manually or electrically operate the valve to check its flexibility and responsiveness when opening and closing. Listen to the sounds during valve operation to identify issues that abnormal noises may indicate.

Emergency Shut-off Valve Test: Test the emergency shut-off valve under simulated emergency conditions to verify its rapid response and reliability. Ensure that the emergency shut-off valve can cut off the medium flow within the specified time in actual applications.

Long-term Maintenance and Safety Considerations


Long-term maintenance and safe operation of the valve are important factors in ensuring its continuous and stable operation. Developing reasonable maintenance plans and safety procedures can prevent potential risks and failures.

Regular Maintenance: Develop a regular maintenance plan for the valve, including cleaning, inspection, lubrication, and replacement of worn parts. Monitor the performance of the valve to identify and resolve potential issues promptly.

Safety Operation Procedures: Develop and implement safety operation procedures to ensure that operators understand the characteristics and operating requirements of the valve. Provide regular training for operators to enhance their safety awareness and operating skills.

Environmental Adaptability: Assess the adaptability of the valve under different environmental conditions and make adjustments or replacements as necessary to adapt to environmental changes.

Special Considerations for Installing Different Types of Valves


Different types of valves may require special installation techniques and considerations. Understanding these special requirements can help technicians complete the installation work more effectively.

Non-metallic Valves: Understand the physical properties of non-metallic valves, such as hardness, brittleness, and strength, and take appropriate installation and operation measures. Avoid applying excessive force to non-metallic valves to prevent damage or rupture.

Proper Use of Seals: Adjust the compression force of the seal ring according to its material and the operating conditions of the valve. Regularly check the wear condition of the seal ring and replace it in time to maintain sealing performance.

Thermal Expansion of High-temperature Valves: Consider the issue of thermal expansion of high-temperature valves with temperature changes and design a suitable bolt tightening scheme. After the valve is put into use, adjust the bolt tightening torque in a timely manner according to the actual temperature changes.

With the continuous advancement of technology and the increasing industrial demands, the installation and maintenance of industrial valves have become an indispensable part of the engineering field. The valve installation guide provided in this article covers the entire process from early preparation to later maintenance, including detailed operational tips for special valves. We hope that this guide can become a valuable assistant for engineers and technical personnel during the valve installation process, helping them avoid common mistakes, improve work efficiency, and ensure the long-term stable operation of the system.
