High Pressure Trunnion Ball Valve, API 6D, 1500 LB, PN250
Key Specifications / Features
Model no.: JSC-231219-TMBV-02
Hits: 19
Introducing our High Pressure Forged Steel Trunnion Ball Valve, sourced from a reliable supplier. This valve is designed to meet API 6D, ASME B16.34, and DIN 3357 standards, making it suitable for high-pressure applications. Available in sizes ranging from 2 to 48 inches, it is engineered for Class 1500 LB and PN250 pressure ratings. The valve is crafted from durable materials, including Carbon Steel, Stainless Steel, and Alloy Steel, ensuring resilience in various environments.
Request a quote
Tags
Detail Information
High Pressure Forged Steel Trunnion Ball Valve
High-pressure forged steel ball valve is mainly used for long distance pipeline transportation of oil and natural gas and urban gas pipeline system. Due to the unique characteristics of the long distance pipeline valve, the design has fully taken into account its ability to withstand pipeline stress, as well as safety, weather resistance, long-term use of reliable sealing.
Forged Steel Trunnion Ball Valve is usually built by 3-piece body, suitable for various kinds of pipelines, Class 150-4500 LB, PN16-PN720, JIS 5K-JIS 40K, is used to cut off or turn on the pipeline medium, can be operated by worm gear, manual, pneumatic actuator, electric driver, the connection type includes RF Flange, RTJ Flange, Butt welding, Grayloc, etc.
SIZE RANGE AND PRESSURE CLASS
Size Range: 2 Inch-48 Inch (DN50-DN1200)
Pressure Range: Class 150 LB- 2500 LB (PN16-PN420)
DESIGN STANDARDS
Design / Manufacture: API 6D, ASME B16.34, DIN 3357, EN 13709, GB/T 12237, BS 5351, JIS B 2071
Face to Face Length (Dimension): MFG, API 6D, ASME B16.10, EN 558-1, DIN 3202, JIS B 2002
Flanged Dimension: ASME B16.5, EN 1092-1, BS 4504, DIN 2501
Flanged to ASME B16.5 (2 Inch-24 Inch) and ASME B16.47 Series A / B (26 Inch and above).
Butt Welding Ends: ASME B16.25, EN 12982, GB/T 12224
Testing: API 598, API 6D, EN 12266-1, EN 1074-1, ISO 5208, DIN 2401, JIS B 2003.
TECHNICAL FEATURES
Split body, forged steel, side entry design.
3-piece bolted construction permits disassembly in the field for repairs
Stem separated from the ball, no side load on the stem
Tight shut-off sealing mechanism
Explosive decompression-resistant seal
3 Mil Nickel plating for trim parts (Ball, Seat Ring)
Trunnion mounted ball for ease of operation at high pressure (Post and Plate designs)
Double Block & Bleed Capability
Fire Safe Design
Multiple Stem Sealing
Double Isolation & Bleed (DIB) Design Available
Valve cavity pressure relief (SPE Seats)
Built-in sealant injection system for emergency seat & stem seal
Anti-provision Design
Anti-Static Device
Back-seated blowout proof stem
RPTFE, DEVLON, PEEK standard Plastic seat inserts
Acid Gas and High H2S/CO2 applications
CONSTRUCTION MATERIALS
Carbon Steel: ASTM A105, C22.8 / P250GH (1.0460/1.0432)
Low Temperature Carbon Steel (LTCS): ASTM A350 LF2, TStE355 / P355QH1 (1.0571/1.0566)
Alloy Steel: ASTM A350 LF1, LF3, LF5, LF6, LF9, LF787
High Temperature Steel (Chrome Moly)/Alloy Steel: ASTM A182 F1, 15Mo3 / 16Mo3 (1.5415) ASTM A182 F11, 13CrMo4-4 / 13CrMo4-5 (1.7335)
ASTM A182 F22, 10CrMo9-10 / 11CrMo9-10 (1.7383/1.7380)
ASTM A182 F91, X10CrMoVNb9-1 (1.4903)
Austenitic Stainless Steel/Alloy Steel: ASTM A182 F304 X5CrNi1810 / X5CrNi18-10 (1.4301)
ASTM A182 F304L X2CrNi19-11 (1.4306)
ASTM A182 F316 X5CrNiMo 17 12 2 / X5CrNiMo17-12-2 (1.4401)
ASTM A182 F316L X2CrNiMo 17 13 2 / X2CrNiMo17-12-2 (1.4404)
ASTM A182 F316Ti X6CrNiMoTi 17 12 2 / X6CrNiMoTi17-12-2 (1.4571)
ASTM A182 F321 X6CrNiTi 18 10 / X6CrNiTi18-10 (1.4541)
ASTM A182 F347 X6CrNiNb18-10 / X6CrNiTi18-10C (1.4550)
ASTM A182 F44 (6MO) (1.4547)
ASTM A182 F20 (ALLOY 20)
Ferritic-Austenitic / Duplex / Super Duplex Stainless Steel: ASTM A182 F51, X2 CrNiMoN 22 5 3 / X2CrNiMoN22-5-3 (1.4462)
ASTM A182 F52, (1.4460)
ASTM A182 F53, X2CrNiMoCuN 25.6.3 (1.4410)
ASTM A182 F55, X2CrNiMoCuWN 25.7.4 (1.4501)
ASTM A182 F60, (1.4462)
Other materials: Alloy 20, ASTM B462 / UNS N08020
Monel 400 / UNS N04400 / ASTM B564-N04400) / ASTM A494 M35-1, NiCu30Fe (2.4360)
Nickel Alloy 904L / UNS N08904, X1NiCrMoCu25.20.5 (1.4539)
Inconel 625 / UNS N06625 / ASTM B564-N06625 / ASTM A494-CW6MC, NiCr22Mo9Nb (2.4856)
Inconel 825 / UNS N08825 / ASTM B564-N08825 / ASTM A494 CU5MCuC (2.4858), NiCr21Mo (2.4858)
High-pressure forged steel ball valve is mainly used for long distance pipeline transportation of oil and natural gas and urban gas pipeline system. Due to the unique characteristics of the long distance pipeline valve, the design has fully taken into account its ability to withstand pipeline stress, as well as safety, weather resistance, long-term use of reliable sealing.
Forged Steel Trunnion Ball Valve is usually built by 3-piece body, suitable for various kinds of pipelines, Class 150-4500 LB, PN16-PN720, JIS 5K-JIS 40K, is used to cut off or turn on the pipeline medium, can be operated by worm gear, manual, pneumatic actuator, electric driver, the connection type includes RF Flange, RTJ Flange, Butt welding, Grayloc, etc.
SIZE RANGE AND PRESSURE CLASS
Size Range: 2 Inch-48 Inch (DN50-DN1200)
Pressure Range: Class 150 LB- 2500 LB (PN16-PN420)
DESIGN STANDARDS
Design / Manufacture: API 6D, ASME B16.34, DIN 3357, EN 13709, GB/T 12237, BS 5351, JIS B 2071
Face to Face Length (Dimension): MFG, API 6D, ASME B16.10, EN 558-1, DIN 3202, JIS B 2002
Flanged Dimension: ASME B16.5, EN 1092-1, BS 4504, DIN 2501
Flanged to ASME B16.5 (2 Inch-24 Inch) and ASME B16.47 Series A / B (26 Inch and above).
Butt Welding Ends: ASME B16.25, EN 12982, GB/T 12224
Testing: API 598, API 6D, EN 12266-1, EN 1074-1, ISO 5208, DIN 2401, JIS B 2003.
TECHNICAL FEATURES
Split body, forged steel, side entry design.
3-piece bolted construction permits disassembly in the field for repairs
Stem separated from the ball, no side load on the stem
Tight shut-off sealing mechanism
Explosive decompression-resistant seal
3 Mil Nickel plating for trim parts (Ball, Seat Ring)
Trunnion mounted ball for ease of operation at high pressure (Post and Plate designs)
Double Block & Bleed Capability
Fire Safe Design
Multiple Stem Sealing
Double Isolation & Bleed (DIB) Design Available
Valve cavity pressure relief (SPE Seats)
Built-in sealant injection system for emergency seat & stem seal
Anti-provision Design
Anti-Static Device
Back-seated blowout proof stem
RPTFE, DEVLON, PEEK standard Plastic seat inserts
Acid Gas and High H2S/CO2 applications
CONSTRUCTION MATERIALS
Carbon Steel: ASTM A105, C22.8 / P250GH (1.0460/1.0432)
Low Temperature Carbon Steel (LTCS): ASTM A350 LF2, TStE355 / P355QH1 (1.0571/1.0566)
Alloy Steel: ASTM A350 LF1, LF3, LF5, LF6, LF9, LF787
High Temperature Steel (Chrome Moly)/Alloy Steel: ASTM A182 F1, 15Mo3 / 16Mo3 (1.5415) ASTM A182 F11, 13CrMo4-4 / 13CrMo4-5 (1.7335)
ASTM A182 F22, 10CrMo9-10 / 11CrMo9-10 (1.7383/1.7380)
ASTM A182 F91, X10CrMoVNb9-1 (1.4903)
Austenitic Stainless Steel/Alloy Steel: ASTM A182 F304 X5CrNi1810 / X5CrNi18-10 (1.4301)
ASTM A182 F304L X2CrNi19-11 (1.4306)
ASTM A182 F316 X5CrNiMo 17 12 2 / X5CrNiMo17-12-2 (1.4401)
ASTM A182 F316L X2CrNiMo 17 13 2 / X2CrNiMo17-12-2 (1.4404)
ASTM A182 F316Ti X6CrNiMoTi 17 12 2 / X6CrNiMoTi17-12-2 (1.4571)
ASTM A182 F321 X6CrNiTi 18 10 / X6CrNiTi18-10 (1.4541)
ASTM A182 F347 X6CrNiNb18-10 / X6CrNiTi18-10C (1.4550)
ASTM A182 F44 (6MO) (1.4547)
ASTM A182 F20 (ALLOY 20)
Ferritic-Austenitic / Duplex / Super Duplex Stainless Steel: ASTM A182 F51, X2 CrNiMoN 22 5 3 / X2CrNiMoN22-5-3 (1.4462)
ASTM A182 F52, (1.4460)
ASTM A182 F53, X2CrNiMoCuN 25.6.3 (1.4410)
ASTM A182 F55, X2CrNiMoCuWN 25.7.4 (1.4501)
ASTM A182 F60, (1.4462)
Other materials: Alloy 20, ASTM B462 / UNS N08020
Monel 400 / UNS N04400 / ASTM B564-N04400) / ASTM A494 M35-1, NiCu30Fe (2.4360)
Nickel Alloy 904L / UNS N08904, X1NiCrMoCu25.20.5 (1.4539)
Inconel 625 / UNS N06625 / ASTM B564-N06625 / ASTM A494-CW6MC, NiCr22Mo9Nb (2.4856)
Inconel 825 / UNS N08825 / ASTM B564-N08825 / ASTM A494 CU5MCuC (2.4858), NiCr21Mo (2.4858)
