Double Acting Ball Valve, Pneumatic Actuator, 2-56 Inch, 150-2500 LB
Key Specifications / Features
Model no.: JSC-231117-TMBV-08
Hits: 11
Elevate control and efficiency with our Double Acting Ball Valve Producer, offering versatility with both Trunnion and Floating Ball designs. Paired with a Spring Return Pneumatic Actuator, these valves are engineered for precise automation. Available in sizes ranging from 2 to 56 inches, with Class ratings of 150-2500 LB, and complying with API 6D, ASME B16.34, and BS 5351 standards, our valves provide reliable solutions for diverse industrial applications.
Request a quote
Tags
Detail Information
Double Acting Ball Valve
Double Acting Ball Valve Means the ball valve is actuated by Pneumatic Actuator, which is Double Acting type, there are also Single Acting Type, which depends on the customer/end user’ requirement. there full-bore type and reduced port, floating ball and trunnion ball. Full port type can be used for pigging. Trunnion type is usually for big size pipeline.
We offers the below valves
Double Acting Pneumatic Ball Valve
Single Acting Ball Valve, Trunnion Ball, Floating Ball
Spring Return Pneumatic Actuated Ball Valve
Gas Over Oil Actuated Valves
Hydraulic & Electric Actuated Ball Valve
SIZE RANGE AND PRESSURE CLASS
Size from 2 Inch to 56 Inch (DN50-DN1400)
Pressure from 150 LBS to 2500 LBS (PN16-PN420)
DESIGN STANDARDS
Design / Manufacture as per the standards:API 6D, ASME B16.34, DIN 3357, EN 13709, GB/T 12237, BS 5351, JIS B2071
Face to Face Length (Dimension) as per the standards: ASME B16.10, EN 558-1 Gr. 14 (DIN 3202-F4), DIN 3202-F5, DIN 3202-F7, BS 5163
Flanged Dimension according to the standards: ASME B16.5, EN 1092-1, BS 4504, DIN 2501,
Flanged to ASME B16.5 (2 - 24 Inch) and ASME B16.47 Series A / B (26 Inch and above) Clamp / Hub ends on request.
Testing according to the standards: API 598, API 6D, EN 12266-1, EN 1074-1, ISO 5208, DIN2401, JIS B2003
TECHNICAL FEATURES
Forged Steel, Cast Steel
Reduce Bore, Full Port
Split body, side entry design.
Tight shut-off sealing mechanism
Double Block & Bleed
Fire Safe Design
Valve cavity pressure relief (SPE Seats)
Anti-provision Design
Anti-Static Device
Anti-Blowout stem
CONSTRUCTION MATERIALS
General Cast Carbon Steel:
ASTM A216 WCB, WCC, WCA, GP240GH 1.0619 / GS-C25
ASTM A105, C22.8/ P250GH (1.0460/1.0432)
Low Temperature Carbon Steel (LTCS):
ASTM A352 LCB, LCC, LCA, GS-CK25
ASTM A350 LF2, TStE 355 / P355QH1 (EN 1.0571/1.0566)
Alloy Steel:
ASTM A352 LC1, LC2, LC2-1, LC3, LC4, LC9, ASTM A743 CA6NM
GS-CK16, GS-CK24, GS-10Ni6, GS-10ni14
ASTM A350 LF1, LF3, LF5, LF6, LF9, LF787
High Temperature Steel (Chrome Moly)/Alloy Steel:
ASTM A217 WC1, WC6, WC9, C5, C12, C12A,
GS-22Mo4 / G20Mo5 (EN 1.5419), GS-17CrMo55 / G17CrMo5-5 (EN 1.7357)
ASTM A182 F1, 15Mo3 16Mo3 (EN 1.5415)
ASTM A182 F11, 13 CrMo 4 4 / 13CrMo4-5 (EN 1.7335)
ASTM A182 F22, 10CrMo 9 10 / 11CrMo9-10 (EN 1.7383/1.7380)
ASTM A182 F91, X10CrMoVNb9-1 (EN 1.4903)
Austenitic Stainless Steel/Alloy Steel:
UNS S30400, S30403, S30409, ASTM A351 CF8, CF3, CF10
G-X6CrNi189 / GX5CrNi19-10 (EN 1.4308)
UNS S31600, S31603, S31609, ASTM A351 CF8M, CF3M. CF10M
GX5CrNiMo19-11-2 / G-X6CrNiMo18.10 (EN 1.4408)
UNS S34700, S34709, ASTM A351 CF8C
G-X5CrNiNb189 / GX5CrNiNb19-11 (EN 1.4552)
AISI 316Ti, X6CrNiNo17122 / X6CrNiMoTi17-12-2 (EN 1.4571)
ALLOY 20 / UNS N08020, ASTM A351 CN7M
ASTM A182 F304 X5CrNi1810 / X5CrNi18-10 (EN 1.4301)
ASTM A182 F304L X2 CrNi 19 11 (EN 1.4306)
ASTM A182 F316 X5CrNiMo 17 12 2 / X5CrNiMo17-12-2 (EN 1.4401)
ASTM A182 F316L X2 CrNiMo 17 13 2 / X2CrNiMo17-12-2 (EN 1.4404)
ASTM A182 F316 Ti X6 CrNiMoTi 17 12 2 / X6CrNiMoTi17-12-2 (EN 1.4571)
ASTM A182 F321 X6 CrNiTi 18 10 / X6CrNiTi18-10 (EN 1.4541)
ASTM A182 F347 X6CrNiNb1810 / X6CrNiTi18-10C (EN 1.4550)
ASTM A182 F44 (6MO) (EN 1.4547)
ASTM A182 F20 * (ALLOY 20)
Ferritic-Austenitic / Duplex / Super Duplex Stainless Steel:
UNS S31803 / S32205 (Duplex 2205), ASTM A890/A995 GR.4A (UNS J92205) / A351 CD3MN
UNS S32750 (Super Duplex 2507), ASTM A890 / A995 GR.5A / A351 CE8MN (CD4MCu)
UNS S32760, ASTM A890 / A995 GR.6A (CD3MWCuN)
ASTM A182 F51, X2 CrNiMoN 22 5 3 / X2CrNiMoN22-5-3 (EN 1.4462)
ASTM A182 F52 (EN 1.4460)
ASTM A182 F53, X2CrNiMoCuN 25.6.3 (EN 1.4410)
ASTM A182 F55, X2CrNiMoCuWN 25.7.4 (EN 1.4501)
ASTM A182 F60 (EN 1.4462)
Other Materials:
Alloy 20 ASTM B462 / UNS N08020
Monel 400 / UNS N04400 ASTM B564-N04400 / A494 M35-1 NiCu30Fe (EN 2.4360)
Nickel Alloy 904L / UNS N08904 X1NiCrMoCu25.20.5 (EN 1.4539)
Inconel 625 / UNS N06625 / ASTM B564-N06625 / ASTM A494-CW6MC
NiCr22Mo9Nb (EN 2.4856)
Inconel 825 / UNS N08825 / ASTM B564-N08825 / ASTM A494 CU5MCuC (EN 2.4858)
NiCr21Mo (EN 2.4858)
